LED Screen
Outdoor
V8T
by ROE
Market leading outdoor mesh screen
8.93
Pixel Pitch
18.2
Weight per Tile
112
Horizontal Resolution
112
Vertical Resolution
Physical Dimensions
| Weight | 18.20kg |
| Height | 100.0cm |
| Width | 100.0cm |
| Depth | 9.5cm |
Technical Specifications
| Pixel Pitch | 8.93 mm |
| Weight per Tile | 18.2 kg |
| Horizontal Resolution | 112 px |
| Vertical Resolution | 112 px |
| Transparency | 50 % |
| Brightness | 4000 NITS |
| IP Rating | IP65 |
| Power Consumption 100% (per tile) | 480 |
| Earth Leakage per m² | 1.2 |
| Refresh Rate | 3840Hz |
| Grey Scale Bit Depth | 14bit |
| Maximum Hanging | 22 tiles |
| Processing Platform | Brompton |
| Data Connectors | Ethercon |
| Power Connectors | True1 |
| Indoor/Outdoor | Outdoor |
| Viewing Angle (H) | 160 ° |
| Viewing Angle (V) | 160 ° |
| Curving (Concave) | 10 |
| Curving (Convex) | 10 |
| Touring Frames | Yes (request specifications) |
Key Features
| Maximum Stacking (Dolly) | 2 |
| Tiles Per Dolly | 6 |
| Maximum Flown Height | 22m |
| Maximum Stacked Height | 6m |
